Touch-controlled Real Wireless Stereo Wireless Headset User Handbook

Model ES01

Earphone accessories

Big earmuffs

Middle earmuffs

Small earmuffs

Microphone

Multifunctional keys

Breathing lamp

Charging metal contacts

Battery indicator

Left ear charging indicator

Charging interface of charging seat

Charging Metal Bullet Needle

Right ear charging indicator

Headphone Charging/Placement Warehouse

Charging Metal Bullet Needle

Charging box switch



Start using

First using

Put left and right headphones into the charging cabin for activation.

Note: Headphones will be charged when they are put into the charging cabin. The display area of the charging cabin will show the current headphone power. The headphone indicator will indicate the charging status. If you can't charge, please insert a USB data line to charge the charging cabin. (Detailed operation is explained later.)

Binaural pairing



After putting the headphones into the charging cabin for activation, take out two headphones. The headphones automatically turn on with the prompt sound "power on", then the two ears will automatically form a team. After the team is successful, the left headphones will have the prompt sound "left channel", and the right headphones will have the prompt sound "right channel", at which time the two ears will enter the matching state. Bluetooth mobile search device "ES01" and link, the link is successful with the prompt sound "link success", you can complete the mobile phone and binaural links.

Note: You have 3 minutes to complete the link between your ears and your mobile phone, otherwise the headset will quit the matching mode and shut down automatically. Re-placing the headphones back into the charging cabin and removing them again can activate the pairing again.



Monaural pairing



Take out a headphone from the charging cabin, and the headphone will voice "power on" and then prompt "paring" to enter the single ear matching mode. At this time, the Bluetooth search device "ES01" and link. When the link is successful, the link between the mobile phone and the single ear can be completed.

Reset system



If the misoperation of headphones causes two headphones to be unable to form a team or link to the mobile phone, the system can be reset to restore the factory settings in the following way. In the shutdown state, both ears press the touch button for 10 seconds at the same time until the indicator lights are turned off and the headphones are turned off automatically. Press the double-ear touch button for about 1 second to turn on, the indicator flashes, and the double-ear will automatically form a team successfully. At this time, the system has been reset, and the mobile phone can search for headphones for links.



Wear headphones correctly

Place earphones with ear caps in the ear canal and rotate gently until they fit comfortably without falling off. The wrong way to wear headphones can affect the signal and sound quality.

The right way of wearing



The wrong way of wearing

Tip: To achieve the best sound effect, choose ear caps that completely seal your ear canal. It is possible that different sizes of earcaps are needed for the left and right ears.

Display screen lighting mode



The display will be lit up in the following circumstances, each time for half a minute, and then will be automatically extinguished.

When the left or right ear is put in/out of the charging cabin

When charging cabin charging wire is inserted/pulled out

When USB Output Interface has Mobile Access/Pull-out

Charging ways

Charge headphones

Put the headphones in the charging cabin (metal contacts are relative), the indicator lights will be on for a long time during charging, and the indicator lights will be off after charging.



Charge the headphone cabin

Charge the headphone cabin with the distributed USB data line. When charging begins, the display will display the power of the main battery, which will be extinguished after 30 seconds.

Emergency Charging for Mobile Phone

The mobile phone can be charged by inserting the charging line into the charging socket of the mobile phone (Android or Apple) and connecting it to the USB output interface of the headphone cabin.

Tip: When emergency charging of mobile phone is needed, please first look at the power display of main battery in headphone cabin. When the residual electricity is too low, the optimal charging effect can not be achieved.



Functional Essentials

Long press

Click

double-click

Boot up

Method 1: After the headphone is removed from the headphone compartment, it will start automatically.

Method 2: When the earphone is off, press the touch button for about 3 seconds.

Shutdown

Method 1: Put the headphones in the headphone cabin and shut down automatically.

Method 2: When the earphone is on standby, press the touch button for about 3 seconds to turn off the phone.

Tip: When headphones are playing music or talking, it is not allowed to turn off manually. This function is invalid.

Answer/hang up the phone

When calling, just press the left or right earphone touch button to connect the phone, press again, hang up the phone.



Rejection of calls

When calling, press and hold any left or right earphone touch button for about 3 seconds to reject the call.

Headset and mobile phone call transfer

During the call, long press any left and right earphone touch button for about 3 seconds to switch

Turn mute on/off

During the call, double-click any left or right earphone touch button to turn on mute; double click again to turn mute

Pause /play

When playing music, short press any left and right headphones to touch the button to pause; press again to resume playback



Switch up and down

When playing music, double-click the left ear touch button to switch to the previous song, double-click the right ear touch button to switch to the next song.

Volume plus/minus

When playing music, long press the left ear touch button to decrease the volume, long press the right ear touch button to increase the volume.

Tip: This feature is only available when the music is playing.

Turn on voice assistant

In the standby mode, double-click any of the left and right earphone touch buttons. Activate mobile phone voice assistant (Apple system siri, Android system requires mobile phone to support this function)

Double click any key

Chinese and English tone switching

In the standby state, you can switch between Chinese and English prompt voice by three consecutive clicks of any left and right earphone touch buttons.

Three consecutive clicks

Product parameters

Model:ES01

Communication distance: about 20 meters (under barrier-free environment)

Bluetooth version: V5.0+EDR

Headphone working time: about 3 hours

Headphone standby time: about 50 hours

Charging time: about 2 hours

Type of battery : Polymer lithium ion battery

Support Agreement: HFP/HSP/A2DP/AVRCP

Headphone battery capacity: 3.7V 50mah

Headphone charging time: about 1 hour

Headphone compartment battery capacity: 3.7V 2000mah

Headphone compartment charging time: about 4 hours

Note: All technical information is subject to actual performance.

Tips

1.Please read the instructions carefully before using the product and keep it in a safe place.

2.For the first time, please fully charge this product first.

3.If the product has not been used for a long time (more than 1 month), please charge it

4.You must select a charger from a regular manufacturer to charge it to avoid product damage.

5.If the phone cannot search for a Bluetooth headset, make sure the Bluetooth headset is paired. If the mobile phone program is wrong, please restart the phone and try again; if the Bluetooth headset program is wrong, please restart the Bluetooth headset or restore the factory settings and try again.

Warning

1. Do not dismantle or repair the modified earphone for any reason, otherwise it may cause fire electronic breakdown or even completely damage the product.

2. Do not place the device in an environment where the temperature is too low or too high (below 0 degrees or above 45 degrees)

3. Please avoid using the device indicator near the eyes of children or animals.

4. Do not use the device during thunderstorms. Thunderstorms can cause the device to work abnormally and increase the risk of electric shock.

5. Do not wipe this product with oily and other volatile liquids.
